PV-POWERVENT In-line Centrifugal Duct Fan

In-line/Sidewall Duct Fan Series

PV Model

Model Features

  • Exhaust air up to 943 CFM with static pressure capabilities to 1-1/2" w.g.
  • Galvanized steel casing with black baked enamel coating
  • Pre-wired junction box
  • Ideal for applications where space is limited
  • Non-overloading backward inclined wheel for efficiency at higher static pressures
  • AMCA Seal for Air Performance
  • cULus Listed, Standard 507 & 705

AMCA Seal for Air cULus ETL

Model Overview

The PV-POWERVENT series of direct drive centrifugal in-line duct ventilation fans consists of twelve model sizes 4", 5", 6", 8", 10" and 12.4" respectively. All models are designed for direct connection in-line with standard diameter round ducting. Airflow performance values range from 153 CFM (PV-100X) up to 943 CFM (PV-315X).

All PV fan models incorporate a powerful external rotor motor that has been factory matched to a non-overloading backward curved centrifugal fan wheel.

This powerful combination enables the fan to deliver exceptional airflow performances against high static pressure typically found in ducted ventilation systems. All motors within PV fans are fully speed controllable using voltage or frequency control regulators.

The PV series of duct exhaust or supply fans have been specifically designed for simple installation and many years of maintenance-free operation. These fans can be mounted at any angle and any point along the duct. The totally enclosed motor design allows the PV fans to operate in high moisture, lint, and dust-laden air. All models are manufactured with high-quality materials and artistry that is supported by a comprehensive five (5) year warranty.

All PV Fans feature a corrosion resistant galvanized steel casing with black baked enamel coating and are supplied with a strong mounting bracket and prewired junction box.

The PV-100X fans feature Class F motor insulation.

5-year fan housing and motor warranty

Part ID Duct Dia. Max. CFM Nom. RPM Voltage / Frequency Max. Watts Current Max. SP Max. Temp. of
Transported Air
PV-100X 4" 153 2880 115V / 60Hz 84W 0.8A 1.85" 158°F
PV-125X 5" 206 2745 115V / 60Hz 85W 0.8A 1.77" 158°F
PV-150X 6" 390 2750 115V / 60Hz 135W 1.0A 2.05" 158°F
PV-200X 8" 544 2930 115V / 60Hz 180W 1.76A 2.64" 158°F
PV-250X 10" 618 3045 115V / 60Hz 214W 1.5A 2.8" 158°F
PV-315 12.4" 669 2920 115V / 60Hz 200W 1.5A 2.21" 158°F
PV-315X 12.4" 943 2730 115V / 60Hz 365W 2.4A 3.9" 158°F

HVI CERTIFIED PERFORMANCE

Model Duct (IN) Discharge Speed Setting Speed Setting SP Rated CFM Rated Watts ESTAR Meets Vermont Efficiency Reqs
PV-100X 4 Horizontal HS 0.2 130 - No No
0.4 114 -
0.6 101 -
PV-125X 5 Horizontal HS 0.2 170 - No No
0.4 142 -
0.6 116 -
PV-150X 6 Horizontal HS 0.2 390 128 No Yes
0.4 337 -
0.6 277 -
PV-200X 8 Horizontal HS 0.2 490 175 No Yes
0.4 430 -
0.6 380 -
PV-250X 10 Horizontal HS 0.2 570 174 No Yes
0.4 536 -
0.6 497 -
Dimensional drawing for the PV models.

Dimensions A through G are displayed in inches and rounded to the nearest thousandth of an inch.

Size ø A ø B C D E F ø G Avg. Ship Weight
(lbs)
100 3.813 3.813 4.750 7.688 7.500 4.750 9.563 7
125 4.813 4.813 4.750 7.813 7.500 4.750 9.563 7
150 5.813 5.813 4.750 8.438 9.313 4.750 13.125 7
200 7.813 7.813 4.750 8.750 9.313 4.750 13.125 11
250 9.750 9.750 4.750 8.063 9.313 4.750 13.125 13
315 12.938 12.938 4.750 9.188 10.563 4.750 15.813 21

PV-POWERVENT Fan Kits

The PV-POWERVENT Series fans are also available as easy-to-install kits. This ultra-powerful bathroom fan offers a choice of single or dual vent exhaust. These kits are used for installations that require long or complicated duct runs.

Standard Exhaust Kit

KIT-PV100X

KIT-PV100X

  • 1 PV100X exhaust fan
  • 1 plastic round grille (PG-100)
  • Mounting bracket
KIT-PV150X

KIT-PV150X

  • 1 PV150X exhaust fan
  • 1 plastic round grille (PG-150)
  • Mounting Bracket

Deluxe Exhaust Kit

KIT-PV100X-DV

KIT-PV100X-DV

  • 1 PV100X exhaust fan
  • 2 plastic round grilles (PG-100)
  • 1 Y-fitting (SY-4)
  • Mounting Bracket
KIT-PV150X-DV

KIT-PV150X-DV

  • 1 PV150X exhaust fan
  • 2 plastic round grilles (PG-150)
  • 1 Y-fitting (SY-6)
  • Mounting Bracket
KIT-PV200X-DV

KIT-PV200X-DV

  • 1 PV200X exhaust fan
  • 2 plastic round grilles (BOR-200)
  • 1 Y-fitting (SY-8)
  • Mounting Bracket

PV-POWERVENT Dryer Booster Kits

Clothes Dryer Boosting Kits are available to make install a breeze. These kits include ultra-powerful fans and accessories to help overcome high static pressure caused by long or complicated duct runs. Learn more about clothes dryer boosting

PV-100XPS

Clothes Dryer Exhaust Booster Kit with Integrated Pressure Sensor Switch

PV-100XPS

  • PV-100X
  • Integrated Air Pressure Sensing Switch with electronic cycle timing board
  • Fan Mounting Bracket
PV-100XPS

Clothes Dryer Exhaust Booster Kit with Current Sensor

DBF-100XC

  • PV-100X
  • CS-325 High Current Sensing Switch
  • Fan Mounting Bracket
PV-100XPS

IL Kit

IL-115 & IL-230

  • PV-100X
  • 115V interlock for gas dryers or 230V for electric dryers
  • Fan Mounting Bracket

Standard Accessories

BOC Interior Air Valve Metal Submittal
BOR Interior Air Valve Plastic Submittal
CS-325 Current Sensor Submittal
EPBT-60 Electronic Push Button Timer Submittal
GRA Aluminum Exterior Fixed Grille Submittal
LT-100 Lint Trap Submittal
MD Motorized Backdraft Damper Submittal IOM
PER-CN High-Pressure Aluminum Louver Shutter Submittal
PER-W Plastic Louvered Shutter Submittal
PG Premium Grille/Collar Submittal
SC Speed Control Submittal
SCS5 Speed Control Slide Type Submittal
SIL Acoustic Attenuators Submittal
SPT-100X Pressure Sensor Submittal
SR Reducer Submittal
SY Y Sheet Metal Adapter Submittal
VL Vent Light Submittal

Product Line Overview PreviewDownload
Inline Fan Options Brochure Preview Download
General Catalog Section Preview Download
Typical Specification Sheet Preview Download
Submittal PreviewDownload
IOM PreviewDownload
