SQD and eSQD Direct Drive Square Inline Centrifugal Duct Fans

In-line/Sidewall Duct Fan Series

SQD Model

Model Features

  • Exhaust air up to 2,800 CFM in high static pressure applications up to 1" w.g.
  • Direct drive units have low sound levels and quiet operation
  • Ideal for applications where space is limited
  • Non-overloading backward inclined wheel for efficiency at higher static pressures
  • AMCA Air and Sound Licensed
  • cULus Standard 705 Listed
  • Ecowatt® (eSQD Models ONLY)
  • This product meets the requirements of Buy American (2009) and Build America, Buy America (BABA), as part of IIJA (2022). Download letter here.

AMCA Air and Sound cULus   Ecowatt   BABA-ACT

Model Overview

The SQD square inline duct mounted fan is available in sizes 6 through 15, moving up to 2,800 CFM, with static pressure capability up to 1". eSQD with electronically commutated (EC) motors are square inline duct mounted fan is available in sizes 8, 10, and 12. SQD units are the perfect selection for clean air applications where space is a leading consideration. The compact housing with removable access doors and side discharge capability can be mounted in any orientation.

The eSQD comes with S&P's Electronically Commutated Motor which offers the energy efficiency of a DC motor with the ease of maintenance of DD motors. The eSQD motors have mounted potentiometer and can be controlled by a 0-10V signal.

2 year fan housing warranty, 1 year motor warranty

SQD Specifications

Size CFM Range Max SP
6 93 to 424 1"
8 149 to 503 1/4"
10 305 to 1,076 1/2"
12 529 to 1,686 1/2"
15 793 to 2,879 3/4"

eSQD Specifications

Size CFM Range Max SP
6 83 to 269 5/8"
8 202 to 820 3/4"
10 292 to 1,578 1"
12 500 to 2,344 1"
15 1,178 to 3,720 3/4"
Dimensional drawing for the SQD model.

SQD

Dimensional data is displayed in inches.

Size A B C D E F G
6 13 14 8-7/8 17-3/4 10 11 16-1/2
8 16 17 11-7/8 20-3/4 13 14 19-1/2
10 19 20 13-7/8 23-3/4 16 17 22-1/2
12 23 24 15-7/8 27-3/4 20 21 26-1/2
15 28 29 19-7/8 32-3/4 25 26 31-1/2

eSQD

Dimensional data is displayed in inches.

Size A B C D E F G
6 13 14 8-7/8 17-3/4 10 11 16-1/2
8 16 17 11-7/8 20-3/4 13 14 19-1/2
10 19 20 13-7/8 23-3/4 16 17 22-1/2
12 23 24 15-7/8 27-3/4 20 21 26-1/2
15 28 29 19-7/8 32-3/4 25 26 31-1/2

Standard Accessories

Mounted and Wired Disconnect
Filter Box Submittal
Side Discharge
Belt Guard
Motor Cover
Inlet Guard
Outlet Guard
Hanging Bracket/Mounting Foot with Hanging Spring Isolator
Hanging Spring Isolator
Hanging Rubber in Shear Isolator
Assorted Disconnects
Heavy-duty Disconnect
Backdraft Damper Submittal
Insulated Housing

Ecowatt® Accessories

Constant Pressure System
Potentiometer Submittal
ECM Speed Control
EC Differential Pressure Control IOM
ECM Multispeed Control IOM

Product Line Overview PreviewDownload
Mitigating COVID-19 in the Workplace PreviewDownload
Ecowatt® Brochure PreviewDownload
General Catalog Section Preview Download
Typical Specification Sheet (eSQD) Preview Download
Submittal (SQD) PreviewDownload
Submittal (eSQD) PreviewDownload
IOM (SQD) PreviewDownload
IOM (eSQD) PreviewDownload

  • General/Clean Air
  • Spark Resistant
  • Offices/Common Areas
