L3E and L3S Belt Drive Sidewall Propeller Exhaust/Supply Fans

Sidewall Propeller Fan Series

L3 Models

Model Features

  • Exhaust air up to 85,000 CFM in high static pressure applications up to 1" w.g.
  • Heavy-gauge galvanized steel panel
  • Die formed galvanized steel blades
  • AMCA Air and Sound Licensed
  • cULus 705 Listed

AMCA Air and Sound cULus

Model Overview

L3E (exhaust) and L3S (supply) are high capacity wall mounted belt driven propeller fans rated from 35,000 to 85,000, with static pressure capability up to 1" w.g. Their primary application is the exhaust of large volumes of air at a relatively moderate static pressure from commercial, industrial and agricultural buildings such as manufacturing and assembly plants, warehouses, foundries, mills, boiler rooms and equipment rooms.

Wall mounting provides an easy and economical installation. Belt driven fans provide large volumes of air at low fan speed and low noise levels and afford quick, easy performance adjustments. All required accessories are available with Model L.

2-year fan housing warranty, 1-year motor warranty

Size CFM Range Max SP
42 21,683 to 31,344 3/4"
48 23,603 to 43,005 3/4"
54 19,763 to 59,940 3/4"
60 28,162 to 68,178 1"
72 11,736 to 85,089 1"
Dimensional Drawing for the L3E/L3S Model

Dimensional data is displayed in inches.

Size A B C D E F Damper O.D. Sq. Flange
42 48 2 7-1/2 1-1/4 16 24 46-1/2
48 54 2 7-1/2 1-1/4 16 24 52-1/2
54 60 2 7-1/2 1-1/4 20 26 58-1/2
60 66 2 7-1/2 1-1/4 20 26 64-1/2
72 80 2 8 1-1/4 24 28 78-1/2

Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Standard Accessories

Aluminum Construction
Center Pivot Motorized
Dampers for Exhaust and Supply
Disconnect Switches
Extended Lube Lines
Factory Wiring
Filtered Wall Housing Submittal
Gravity Dampers for Exhaust and Supply
Motorized Dampers for Exhaust and Supply
Mounting Angles

General Catalog Section
Typical Specification Sheet

  • General/Clean Air
  • Spark Resistant
