GED/eGED and GSD/eGSD Direct Drive Sidewall Propeller Exhaust/Supply Fans

Sidewall Propeller Fan Series New Product

GD Models

Model Features

  • Exhaust air up to 3,500 CFM in high-pressure applications up to 3/4" w.g.
  • 16 gauge galvanized steel panel
  • Formed flanges for added rigidity
  • Integral OSHA approved motor side guard
  • Fabricated aluminum blades, precision pitch
  • Suitable for all angle installation
  • AMCA Air and Sound Licensed
  • cULus 705 Listed
  • EcoWatt® (eGED/eGSD Models ONLY)

AMCA Air and Sound Licensed   cULus Listed   EcoWatt Registered

Model Overview

The GED/eGED and GSD/eGSD Direct Drive Sidewall Propeller Exhaust/Supply Fan features the maximum efficiency, low maintenance and durable, economical operation resulting from the direct drive design. It is available in exhaust configurations to provide general ventilation for a wide variety of buildings and enclosed areas within buildings. Examples include factories, assembly plants, churches, gymnasiums, garages, jails, machine rooms and many others.

They feature extremely quiet operation and an integral motor side guard as standard.

The eGED and eGSD come with S&P's Electronically Commutated (EC) Motor which offers the energy efficiency of a DC motor with the ease of maintenance of DD motors. The motors are 115V, 60 Hz in 1/3 HP & 1/2 HP and is 230V in 3/4 HP. This fully controllable motor offers both reliability and low maintenance in one of the most efficient motor fan combinations in the industry.

S&P's eGED/eGSD, motors are the ideal solution for a low cost, fully controlled ventilation system. This motor in the eGED/eGSD can move air volumes up to 4,183 CFM.

Industry best 5-year fan housing warranty, 1-year motor warranty

GED and GSD Specifications

Size CFM Range Max SP
10 227 to 782 1/4"
12 544 to 1525 1/2"
14 581 to 2546 5/8"
16 889 to 2676 5/8"
18 902 to 2983 5/8"
20 2112 to 3885 1/2"

eGED and eGSD Specifications

Size CFM Range Max SP
12 489 to 1614 1/2"
14 513 to 2205 3/4"
16 584 to 2882 3/4"
18 599 to 4183 3/4"
20 469 to 3718 3/4"
Dimensional Drawing GD
Size A B C D E F
10 16" 10-1/2" 1" 2" 11" 9"
12 16" 12-1/2" 1" 2" 14" 12"
14 20" 14-1/2" 1" 2" 14" 12"
16 20" 16-1/2" 1" 2" 14" 12"
18 24" 18-1/2" 1" 2" 15" 13"
20 24" 20-1/2" 1" 2" 15" 13"

Mounting Option Description
Wall Housing Heavy-gauge, all galvanized G-90 steel housing provides a simple solution to installing a fan and all required accessories in a rough wall opening. It can be used in exhaust or supply applications and fan sizes 10 to 60 inches.
Filtered Wall Housing For installations where filtering is required. Heavy-gauge, all galvanized, G-90 steel filtered wall housings are available in both supply and exhaust configurations. They are available in nine (9) sizes for fans ranging from size 14 to 60 inches. They are designed with the draw-thru concept to achieve the highest filter and fan efficiencies.
Wall Collar Heavy-gauge, all G-90 galvanized mounting collar provides a simple solution to installing a fan in a rough wall opening when a rear safety guard is NOT required.

Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Standard Accessories

Description
Rainhoods/Weatherhoods   Download
Gravity Dampers for Exhaust and Supply   Download
Motorized Dampers for Exhaust and Supply   Download
Disconnect Switches   Download
Extended Lube Lines   Download
Mounting Angles   Download
Factory Wiring   Download

Description
GED/eGED and GSD/eGSD Catalog Pages   Download
GED and GSD Product Submittal   Download
eGED and eGSD Product Submittal   Download
GED/eGED and GSD/eGSD Product IOM   Download

Description
GED (Exhaust) Revit File
GSD (Supply) Revit File
Exhaust Rainhood (45 degree) Revit File
Supply Rainhood (90 degree) Revit File
