UBS and UBS-P Belt Drive Upblast Propeller Roof Exhaust Fan

Roof Propeller Fan Series

UBS and UBS-P Models

Model Features

  • Exhaust air up to 78,000 CFM in static pressure applications up to 1/2" w.g.
  • Straight-through airflow design results in maximum exhaust efficiency
  • Belt drives permit easy performance adjustments when needed
  • Direct drive units have low sound levels and quiet operation
  • cULus 705 Listed

cULus Listed

Model Overview

UBS (steel propeller) and UBS-P (polyamide/polypropylene propeller) are high capacity roof mounted exhausters rated from 7,000 to 51,000 CFM. They are general ventilation units designed to economically remove large volumes of air, fumes, and vapors from commercial and industrial buildings such as warehouses, manufacturing and assembly plants, chemical plants, foundries and paper mills.

Straight-through airflow design results in maximum exhaust efficiency. During operation, high airflow velocity opens butterfly dampers and prevents rain or snow from entering. Dampers close and cover the venturi opening when the unit is not in use.

The roof-mounted location eliminates interference with processes and equipment inside the building. It also permits locating the exhauster over a source of heated or contaminated air, allowing direct upward venting to the outside, unlike wall mounted exhausters which may move contaminated air through adjacent workspaces.

Belt drive units usually operate more quietly and afford easier performance adjustments, while direct drive models require less maintenance.

2-year fan housing warranty, 1-year motor warranty

UBS Specifications

Size CFM Range Max SP
24 3732 to 7939 1/2"
30 3906 to 14388 1/2"
36 3522 to 19087 1/2"
42 5386 to 25259 1/2"
48 7559 to 31480 1/2"
54 11910 to 36456 1/2"
60 22834 to 50996 1/2"

UBS-P Specifications

Size CFM Range Max SP
24 5010 to 7420 1/2"
30 3010 to 14600 1/2"
36 2930 to 20600 1/2"
42 6270 to 30000 1/2"
48 10500 to 36500 1/2"
54 15400 to 41800 1/2"
60 25700 to 58500 1/2"
Dimensional Drawing UBS
Size A B C D E F
24 30" 26" 20" 32" 28" 31"
30 36" 29" 21" 38" 34" 37"
36 42" 31" 21" 44" 40" 43"
42 48" 34" 22" 50" 46" 49"
48 54" 37" 26" 56" 52" 55"
54 60" 40" 26" 62" 58" 61"
60 66" 43" 26" 68" 64" 67"

Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Standard Accessories

Description
Roof Curb   Download
Outlet Guard   Download
Disconnect Switches   Download
Magnetic Latches   Download
Cushion Close   Download
Safety Basket Guard   Download

Description
UBS and UBS-P Catalog Pages   Download
UBS Product Submittal   Download
UBS-P Product Submittal   Download
UBS and UBS-P Product IOM   Download

  • General/Clean Air
  • Contaminated Air
