TRC Total Recovery for All Climates (Commercial Applications)

Energy Recovery Ventilators

TRC Model

Model Features

  • MERV-8 filters
  • Transformer/relay package allowing simple on/off control
  • Access doors for easy access to blowers, core, and filters
  • Fully insulated case
  • Large cores for high efficiency
  • No condensate pan or drain required
  • AHRI Certified
  • cULus Listed

AHRI cULus

Model Overview

With S&P's TRC (total recovery for commercial applications) Series for all climates, stale room air is exhausted, and the fresh outdoor air is brought back into the building. With this line of ERVs (Energy Recovery Ventilators) these two air streams are directed through a highly developed "air-to-air" energy exchange core. The air streams are physically separated by many layers of "plates" so there is no mixing or contamination of the fresh air. The plates are made of an engineered "resin" material that simultaneously transfers heat by conduction and humidity by attracting and moving water vapor from one air stream to the other.

S&P's TRCs moderate extremes in both temperature and humidity, creating a comfortable indoor environment. The unique moisture transfer capability of the S&P core also eliminates condensation and frost build up in most applications. Unlike other ERVs on the market no mechanical or electrical defrost systems are needed, which means higher heat recovery efficiencies, easier installation and more reliable operation.

Warning Icon WARNING: This product can expose you to chemicals including formaldehyde, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.

10-year core warranty, 2-year unit warranty

Core Performance for TRC500

Airflow CFM ESP in H2O Watts Temp. EFF% Total EFF% Winter/Summer
225 1.25 335 81 76/66
338 1.00 420 77 71/61
380 0.90 470 75 69/59
450 0.65 550 73 66/56
540 0.25 640 70 62/52
575 0.00 690 69 61/51
600 -0.25 735 68 60/50

Airflow Performance for TRC800

Motor HP
Phase
External Static Pressure (Inches Water Column)
0 0.25 0.5 0.75 0.9 1.25 1.5
0.75
Single Phase
970 CFM 925 CFM 860 CFM 795 CFM 750 CFM 635 CFM 480 CFM
1,490 Watts 1,375 Watts 1,270 Watts 1,160 Watts 1,090 Watts 950 Watts 825 Watts

Airflow Performance for TRC1200

Motor HP
Phase
External Static Pressure (Inches Water Column)
0 0.25 0.5 0.75 0.9 1.25 1.5
1.0
Single Phase
1,575 CFM 1,470 CFM 1,350 CFM 1,225 CFM 1,090 CFM 950 CFM 795 CFM
1,545 Watts 1,525 Watts 1,500 Watts 1,475 Watts 1,435 Watts 1,380 Watts 1,300 Watts
1.0
Three Phase
1,675 CFM 1,570 CFM 1,435 CFM 1,280 CFM 1,115 CFM 940 CFM 760 CFM
1,410 Watts 1,400 Watts 1,380 Watts 1,340 Watts 1,280 Watts 1,210 Watts 1,135 Watts

Airflow Performance for TRC1600

Motor HP Blower RPM Turns Open External Static Pressure (in w.g.)
0 0.25 0.5 0.75 0.9 1.25 1.5
SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP SCFM BHP
1.5 1148 4 1592 0.7 1480 0.7 1320 0.6 1120 0.5 800 0.4 - - - -
1304 2 1809 1.0 1720 1.0 1600 0.9 1410 0.8 1250 0.7 975 0.6 630 0.4
1460 0 2025 1.5 1950 1.4 1845 1.3 1715 1.2 1540 1.1 1400 1.0 1165 0.8

Dimensions for TRC500

Dimensional Drawing for the TRC500 Model

Dimensions for TRC800

Dimensional Drawing for the TRC800 Model

Dimensions for TRC1200

Dimensional Drawing for the TRC1200 Model

Dimensions for TRC1600

Dimensional Drawing for the TRC1600 Model
