PCRL Recessed Vent Light Models

Premium CHOICE Series

PCRL Model

Model Features

  • Designed to look like a recessed can light
  • Quiet operation 1.2 Sones
  • PCRL80 has an E26 bulb base (bulb sold separately)
  • PCRL80F has a GU24 bulb base (CFL spiral bulb included)
  • Enclosed condenser motor for long life
  • Motor rated for 30,000 hours continuous on
  • Galvanized housing with black polyester powder coat finish
  • Universal 4 or 5" metal duct adaptor with built-in backdraft damper
  • 14-24" adjustable hanging bars
  • Fits 2x8 construction
  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)

cETLus Listed   ENERGY STAR Qualified   HVI Certified   CALGreen (Title 24 Compliant)

Model Overview

Designed to look like a recessed can light, this fan is certified to move 80 CFM at 0.1" SP. The PCRL gives you innocuous ventilation, a fan you can't see or hear!

5-year warranty

Model Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight
PCRL80 4" and 5" 80 50 1.5 120V / 60Hz 4.1 19.7 0.27A 10 lbs
PCRL80F 4" and 5" 80 50 1.5 120V / 60Hz 4.1 19.7 0.27A 10 lbs
Dimensional Drawing
Size W D H
PCRL80 12-5/8" 8" 7-1/4"
PCRL80F 12-5/8" 8" 7-1/4"

Light Cover Options

PCRL80LC

The Light Cover (PCRL80LC) comes standard with PCRL80F and is optional with PCRL80. The light cover disguises a spiral or non-PAR30 bulb to keep the recessed can light look.

Plug-&-Play Modules

PCHS - Humidity Sensor

  • Detects rapid rise in humidity
  • Auto-shut off timer
  • Accessible sensitivity adjustment
  • Humidity is sensed at the ceiling
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

PCSC - Speed Control

  • Accessible speed adjustment
  • High-speed override
  • Allows for adjustable continuous speed to meet ASHRAE 62.2
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Electrical Controls

Part Description
PC3S 3-Switch Control   Download
FLTD-60 Fan/Light Delay Timer Switch   Download
SRT-30 Rotary Spring Wound Timer   Download
EPBT-60 Electronic Push Button Timer   Download
FT622 ASHRAE 62.2 Bath Fan Ventilation Control   Download
FT247 Programmable Fan Timer   Download

General Accessories

Part Description
PER-W Plastic Louvered Shutter   Download
GRA Aluminum Exterior Fixed Grille   Download
RC Roof Cap   Download
ME Round Adjustable Metal Elbow   Download
DC Duct Connector   Download
WC Worm Clamp   Download

Description
Premium CHOICE Series Brochure   Download
PCRL Catalog Pages   Download
PCRL Product Submittal   Download
PCRL Product IOM   Download
PC Connection Wiring Diagrams for AC Motor   Download

Description
PCRL80 Revit File Download
PCRL80F Revit File Download

  • Residential Bathroom Exhaust
  • Commercial Bathroom Exhaust
  • Local Exhaust
  • Dwelling Unit Ventilation
