PCLP Low Profile Models

Premium CHOICE Series

PCLP Model

Model Features

  • Low profile housing design
  • Quiet operation 1.2 to 2.0 Sones
  • Enclosed condenser motor for long life
  • Motor rated for 30,000 hours continuous on
  • Built-in backdraft damper
  • Robust steel housing
  • Attractive, sturdy grille
  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)

cETLusENERGY STAR HVI CALGreen (Title 24)

Model Overview

The Premium CHOICE Low Profile Ventilation fans feature ultra-low profile housings suitable for both wall and ceiling installations. Installing a PCLP in a wall means that you do not need a radiation damper to meet fire-resistance requirements in the building code like you do when installing the fan in a fire-rated ceiling making the PCLP the more economical CHOICE for multi-family applications.

Contractor Pack

For simple installation, the PCLP is available in four packs with the fan housings ready for installation first. After the drywall and painting are complete, the motor and grilles are available to finish the job. The housing kit includes the housing and hanger bars. The motor and grille kit consists of the motor plate, motor, wheel and standard grille.

Part Description
PCLP PCLP80 Contractor Pack Housings (4pk)
PCLP80F PCLP80 Contractor Pack Motor and Grille (4pk)
PLCP100F PCLP100 Contractor Pack Motor and Grille (4pk)

5-year warranty

Model Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current (Amps) Avg. Ship Weight (lbs)
PCLP80 4" 80 62 1.2 120V / 60Hz 3.1 25.9 0.35 7
PCLP100 100 86 2 4.1 24.6 0.40
Dimensional Drawing for the PCLP Model

Dimensional data is displayed in inches.

Size X Y W D H
PCLP80 13" 14" 10-1/4" 10-1/4" 3-3/4"
PCLP100 13" 14" 10-1/4" 10-1/4" 3-3/4"

Plug-&-Play Grille Options

Lighted Grille Kit

PCLPLEDK

PCLPLEDK - LED Lighted Grille Kit

  • 11 watt LED array (4100K/1100 lumens)
  • 2 watt LED night light setting (200 lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Plug-&-Play Modules

PCLPHS

PCLPHS - Humidity Sensor

  • Detects rapid rise in humidity at the ceiling level
  • Automatic shut-off timer
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
PCLPSC

PCLPSC - Speed Control

  • Accessible speed adjustment
  • High-speed override
  • Allows for adjustable continuous speed to meet ASHRAE 62.2
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Electrical Controls

PC3S 3-Switch Control Submittal
FLTD-60 Fan/Light Delay Timer Switch Submittal
SRT-30 Rotary Spring Wound Timer Submittal
EPBT-60 Electronic Push Button Timer Submittal
FT622 ASHRAE 62.2 Bath Fan Ventilation Control Submittal
FT247 Programmable Fan Timer Submittal

General Accessories

PER-W Plastic Louvered Shutter Submittal
GRA Aluminum Exterior Fixed Grille Submittal
RC Roof Cap Submittal
ME Round Adjustable Metal Elbow Submittal
DC Duct Connector
WC Worm Clamp

Premium CHOICE Series Brochure
General Catalog Section
Submittal (PCLP80)
Submittal (PCLP100)
Instruction and Operation Manual
Connection Wiring Diagram (Premium CHOICE Series with AC Motor)

PCLP80
PCLP100

  • Residential Bathroom Exhaust
  • Commercial Bathroom Exhaust
  • Local Exhaust
  • Dwelling Unit Ventilation
