PCD (High Volume)High Volume DC Motor Models

Premium CHOICE Series

PCD High Volume Model

Model Features

  • Quiet operation, certified at 2.4 Sones
  • Brushless DC motor for long life
  • Motor rated for 60,000 hours continuous on
  • 6" duct connector with built-in backdraft damper
  • Robust galvanized steel housing
  • Attractive, sturdy grille
  • cETLus Listed
  • ENERGY STAR® qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)
  • AMCA Air and Sound Licensed
  • EcoWatt®

cETLus Listed   ENERGY STAR Qualified   HVI Certified   CALGreen (Title 24 Compliant)   AMCA Air and Sound Licensed   EcoWatt Registered

Model Overview

The PCD High Volume fans are designed to solve ventilation issues within restrooms of commercial buildings using the most efficient motors available. The High Volume fans accept humidity sensing modules for the added benefit of worry-free commercial ventilation.

6-year warranty

Model Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight
PCD200 6" 220 189 2.5 120V / 60Hz 7.0 31.3 2.40A 11 lbs
Dimensional Drawing
Size X Y W D H
PCD200 15" 16" 12-7/8" 12-1/2" 7-5/8"

Plug-&-Play Modules

PCHS - Humidity Sensor

  • Detects rapid rise in humidity at the ceiling level
  • Automatic shut-off timer
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Description
Premium CHOICE Series Brochure   Download
PCD200 Catalog Pages   Download
PCD200 Product Submittal   Download
PCD200 Product IOM   Download
PC Connection Wiring Diagrams for DC Motor   Download

Description
PCD200 Revit File Download

  • Residential Bathroom Exhaust
  • Commercial Bathroom Exhaust
  • Local Exhaust
  • Dwelling Unit Ventilation
