PC Standard Size Models with AC Motors

Premium CHOICE Series

PC-SILENT Model

Model Features

  • Extremely quiet operation <0.3 to 1.1 Sones
  • Enclosed condenser motor for long life
  • Motor rated for 30,000 hours continuous on 120V/60Hz, 230V/60Hz or 230V/50Hz motors
  • 4" (PC50X), 4" & 6" (PC80X & PC110X), and 6" (PC150) duct connectors included with built-in backdraft damper
  • Robust steel housing
  • Attractive, sturdy grille
  • cETLus Listed
  • ENERGY STAR® Qualified
  • HVI Certified
  • CALGreen (Title 24 Compliant)
  • AMCA Air and Sound Licensed

cETLus Listed   ENERGY STAR Qualified   HVI Certified   CALGreen (Title 24 Compliant)   AMCA Air and Sound Licensed

Model Overview

Available in 4 sizes with single speed motors (PC50X, PC80X, PC110X, and PC150) the Premium CHOICE AC Standard Models, as the name suggests, is all about the CHOICE! The fans are engineered to accept S&P's PC plug-&-play options: lighted or motion sensing grille kits, and humidity sensing module, VOC sensing module, speed control module, or Bluetooth® speaker module. One fan can be modified to be the exact fan need. You even have the CHOICE to add a control or change the grille after the initial installation.

Contractor Pack

For simple installation, the PC80X and PC110X are available as four packs with the fan housings ready for installation first. After the drywall and painting are complete, the motor and grilles are available to finish the job. The housing kit includes the housing and hanger bars. The motor and grille kit consists of the motor plate, motor, wheel and standard grille.

Part Description
PCH PC80X and PC110X Contractor Pack Housing (4pk)
PC80F PC80X Contractor Pack Motor and Grille (4pk)
PC110F PC110X Contractor Pack Motor and Grille (4pk)

5-year warranty

Model Duct Dia. HVI Certified CFM 0.1" SP HVI Certified CFM 0.25" SP Sones @ 0.1" SP Voltage / Frequency Energy Efficiency (CFM/Watts) Watts @ 0.1" SP Current Avg. Ship Weight
PC50X 4" 50 38 0.9 120V / 60Hz 3.5 16.1 0.2A 7 lbs
PC80X 4" 80 61 1 120V / 60Hz 3.5 24.3 0.27A 11 lbs
6" 90 64 0.5 3.7 24.4
PC110X 4" 110 91 0.9 120V / 60Hz 4.3 27.3 0.30A 11 lbs
6" 130 109 0.9 4.7 27.6
PC150 6" 150 131 1.1 120V / 60Hz 3.6 43.2 0.34A 11 lbs
Dimensional Drawing
Size X Y W D H
PC50X 11-7/16" 11-13/16" 9" 9" 5-3/4"
PC80X 13" 14" 11-3/8" 10-1/2" 7-5/8"
PC110X 13" 14" 11-3/8" 10-1/2" 7-5/8"
PC150 13" 14" 11-3/8" 10-1/2" 7-5/8"

Plug-&-Play Grille Options

Metal Grille

PCMG

PCMG - Metal Grille

  • 13 x 14" metal grille
  • Ideal for commercial applications

Lighted Grille Kit

PCLEDK

PCLEDK - LED Lighted Grille Kit

  • 11 watt LED array (4100K/1100 lumens)
  • 2 watt LED night light setting (200 lumens)
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
PCLK

PCLK - CFL Lighted Grille Kit

  • 13 watt GU24 bulb (2700K/900 lumens)
  • 4 watt night light bulb
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan

Sensing Grille Kit

PCMK

PCMK - Motion Sensing Grille Kit

  • Automatically turns on fan when motion is sensed
  • Adjustable Time Delay Shut-Off from 3 to 30 Minutes
  • Adjustable Speed reduced up to 50%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
PCLMK

PCLMK - Motion Sensing Lighted Grille Kit

  • 13 Watt GU24 Bulb (2700K/900 Lumens)
  • 4 Watt Night Light Bulb
  • Automatically turns on fan when motion is sensed
  • Adjustable Time Delay Shut-Off from 3 to 30 Minutes
  • Adjustable Speed reduced up to 50%
  • Simple Plug-In Receptacle in Fan Housing
  • Can be installed with New or Pre-Installed Fan
PCMHK

PCMHK - Motion and Humidity Sensing Grille Kit

  • Automatically turns fan on when motion and/or rapid rise in humidity is sensed at the ceiling level
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Adjustable time delay shut-off from 3 to 30 minutes
  • Adjustable speed reduced up to 50%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
IOM
PCLMHK

PCLMHK - Motion & Humidity Sensing Lighted Grille Kit

  • 13 watt GU24 bulb (2700K/900 lumens)
  • 4 watt night light bulb
  • Automatically turns fan on when motion and/or rapid rise in humidity is sensed at the ceiling level
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Adjustable time delay shut-off from 3 to 30 minutes
  • Adjustable speed reduced up to 50%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
IOM

Plug-&-Play Modules

PCHS

PCHS - Humidity Sensor

  • Detects rapid rise in humidity at the ceiling level
  • Automatic shut-off timer
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
PCSC

PCSC - Speed Control

  • Accessible speed adjustment
  • High speed override
  • Allows for adjustable continuous speed to meet ASHRAE 62.2
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
PCIAQS

PCIAQS - IAQ Sense, VOC/Humidity Sensor

  • Detects VOCs and/or rapid rise in humidity at the ceiling level
  • Semi-conductor gas sensor, detecting a wide range of VOCs
  • Monitoring range is 400-2000 PPM equivalent CO2
  • Speed control for adjustable continuous speed to meet ASHRAE 62.2
  • Integrated control switch to turn features On/Off
  • Field adjustable humidity sensitivity with 50-100% range, factory setting is 75%
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
PCBTS

PCBTS - Bluetooth® Wireless Speaker

  • High quality Bluetooth® wireless speaker
  • Easy pairing with most Bluetooth® - enabled devices
  • After initial pairing, connection to device is automatic
  • 30 foot Bluetooth® range
  • Simple plug-in receptacle in fan housing
  • Can be installed with new or pre-installed fan
IOM

Note: Additional accessories are available for certain products. Contact your S&P Representative for more information about these accessories.

Radiation Dampers & Kits

PCRD Ceiling Radiation Damper SubmittalIOM
PCMKRD Ceiling Radiation Damper Kit with PCMK Submittal
PCMHKRD Ceiling Radiation Damper Kit with PCMHK
PCLKRD Ceiling Radiation Damper Kit with PCLK Submittal
PCLEDKRD Ceiling Radiation Damper Kit with PCLEDK Submittal
PCLMKRD Ceiling Radiation Damper Kit with PCLMK Submittal
PCLMHKRD Ceiling Radiation Damper Kit with PCLMHKRD
PCMGKRD Ceiling Radiation Damper Kit with PCMG

Electrical Controls

PC3S 3-Switch Control Submittal
FLTD-60 Fan/Light Delay Timer Switch Submittal
SRT-30 Rotary Spring Wound Timer Submittal
EPBT-60 Electronic Push Button Timer Submittal
FT622 ASHRAE 62.2 Bath Fan Ventilation Control Submittal
FT247 Programmable Fan Timer Submittal

General Accessories

PER-W Plastic Louvered Shutter Submittal
GRA Aluminum Exterior Fixed Grille Submittal
RC Roof Cap Submittal
ME Round Adjustable Metal Elbow Submittal
DC Duct Connector
WC Worm Clamp

Replacement Parts

PCDC4 Replacement 4" Duct Connector
PCDC6 Replacement 6" Duct Connector
